Copper Nickel 70/30 Forged Socket Welding Elbow – ASME B16.5 Class150

  • Copper Nickel 70/30 Forged Socket Welding Elbow – ASME B16.5 Class150
  • Copper Nickel 70/30 Forged Socket Welding Elbow – ASME B16.5 Class150
  • Copper Nickel 70/30 Forged Socket Welding Elbow – ASME B16.5 Class150
Lieu d'origine Chine
Nom de marque TOBO
Certification ANSI B16.9/DIN/JIS
Numéro de modèle Coude en cuivre et nickel
Quantité de commande min 1 pièce
Prix Négociable
Détails d'emballage Paquet d'expédition standard
Délai de livraison 15-30 jours de travail
Conditions de paiement T/T, Western Union
Capacité d'approvisionnement 10 tonnes par mois
Détails sur le produit
Pression Haute pression Quantité minimale de commande 1 pièce
Épaisseur Personnalisé Matériel Cuivre Nickel
Connexion soudé Technologie de traitement Forgeage
Application Raccord de tuyau Traitement de surface polissage
Mettre en évidence

Copper Nickel 70/30 forged elbow

,

ASME B16.5 socket welding elbow

,

Class150 Copper Nickel elbow
Laisser un message
Description de produit
Copper Nickel 70/30 Forged Socket Welding Elbow – ASME B16.5 Class150



1. Product Overview & Key Parameters

Our CuNi 70/30 (UNS C71500) forged socket welding elbows are manufactured in strict compliance with ASME B16.5 / B16.11 and Class150 standards. Material: Copper-Nickel 70/30 alloy; Connection: Socket Weld; Type: 45°/90°; Size: 1/2"–6"; Pressure Class: Class150; Process: Hot forging + solution annealing. Dimension accuracy meets international industrial piping requirements, ensuring stable matching and reliable assembly.

2. Core Advantages

  • Superior Corrosion Resistance: Outstanding resistance to seawater, chloride, pitting, and stress corrosion cracking, ideal for long-term service in harsh marine and offshore environments.
  • High Strength & Durability: Forged structure delivers excellent mechanical properties, high pressure resistance, and long service life with low maintenance cost.
  • Excellent Weldability: Compatible with standard welding processes without special pre-treatment, ensuring tight, leak-free joints.

3. Main Applications

Widely used in marine piping systems, desalination plants, offshore oil & gas, shipbuilding, seawater cooling, chemical processing, and power generation. The elbows safely change flow direction while maintaining system integrity under corrosive and high-pressure conditions.

4. Packaging, Shipping & Payment

  • Packaging: Plywood cases with inner foam protection to avoid scratches and deformation during transit.
  • Shipping: Fast lead time; sea/air/express available per request; full tracking provided.
  • Payment: T/T, L/C, Western Union, and other flexible terms to support your project schedule.

5. After-Sales & Service

We offer 12-month quality warranty and comprehensive technical support. In case of material or workmanship defects, we provide free replacement or refund. Custom sizes, angles, and standards are accepted. Contact us now for catalog, quotation, and sample availability!
